1769-OB16 Digital Output Module

The 1769-OB16 digital output module provides sixteen DC sourcing outputs for industrial control applications requiring reliable signal switching and stable field device operation. Its compact structure simplifies installation while maintaining dependable performance in distributed automation systems.

Technical Specifications

Installation Guide

• Disconnect system power before wiring.
• Mount the module securely on the DIN rail or compatible base.
• Connect output wiring according to channel identification.
• Verify power polarity before energizing the system.
• Confirm channel status using the integrated LED indicators after startup.

Typical Applications

• Packaging equipment
• Conveyor control systems
• Material handling lines
• Automated assembly machines
• Process control cabinets
• Factory automation cells
• Motor starter and relay control
• Industrial machine sequencing

FAQ

Q1: What type of outputs does this module provide?
A: It provides sixteen DC sourcing digital outputs.

Q2: Can it control relays and solenoids?
A: Yes, it is commonly used for relays, contactors, indicator lamps, and solenoid valves.

Q3: Is DIN rail installation supported?
A: Yes, it supports standard DIN rail mounting.

Q4: How can output status be checked?
A: Individual LED indicators display channel operating status.

Q5: Where is this module commonly installed?
A: It is widely used in industrial control panels and automated production equipment.
