Omron CQM1-OD212 Digital Output Module — 16-Point NPN | Genuine New In Box
The Omron CQM1-OD212 is a 16-point NPN transistor digital output module for the Omron CQM1 series PLC platform. Rated at DC 12–24V with a response time of ≤1ms and photocoupler isolation on every channel, it delivers the fast, reliable switching that production lines, packaging machines, and automated assembly systems depend on.
✅ 100% genuine Omron product. Factory sealed. Ready for immediate worldwide shipment.
The CQM1-OD212 at a Glance
Three numbers define why engineers reach for this module:
16 output points — the ideal count for mid-size control panels without unnecessary module slots
0.1A per point — sufficient for standard discrete loads: solenoid valves, indicator lamps, relay coils, and small actuators
≤1ms response time — fast enough for high-frequency switching sequences in packaging and assembly applications
Full Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Omron |
| Model | CQM1-OD212 |
| Product Type | Digital Output Module |
| Compatible PLC | Omron CQM1 Series |
| Output Type | Transistor — NPN (sinking) |
| Number of Outputs | 16 points |
| Rated Output Voltage | DC 12–24V (±10%) |
| Max Output Current | 0.1A per point |
| Isolation Method | Photocoupler isolation |
| Response Time (ON) | ≤0.1 ms |
| Response Time (OFF) | ≤0.4 ms |
| Leakage Current | ≤0.1 mA |
| Mounting | CQM1 PLC rack / expansion slot |
| Origin | Japan |
| Condition | Genuine New / Factory Sealed |
💡 Wiring note: The CQM1-OD212 uses NPN (sinking) transistor outputs. This means the load is connected between the output terminal and the positive supply, with the output pulling to common (0V) when active. If your field devices require PNP (sourcing) logic, the CQM1-OD215 is the correct alternative.
Understanding the CQM1-OD212 Model Code
CQM1 - OD - 212
│ │ └─ 212: 16-point NPN transistor output, standard current
│ └───────── OD: Output module, DC transistor type
└──────────────────── CQM1: Omron CQM1 PLC product familyThis naming convention makes it straightforward to identify the correct replacement — if your failed module is marked CQM1-OD212, the part on this page is your exact drop-in replacement.
CQM1 Output Module Comparison — Which One Do You Need?
| Model | Output Points | Output Type | Max Current/Point | Best For |
|---|---|---|---|---|
| CQM1-OD212 | 16 | NPN (sinking) | 0.1A | ⭐ General-purpose panels, standard discrete loads |
| CQM1-OD213 | 32 | NPN (sinking) | 0.1A | High I/O density, machines with many discrete outputs |
| CQM1-OD215 | 8 | PNP (sourcing) | 1.0A | Heavy loads — solenoids, actuators, higher current devices |
How to choose in 3 steps:
- Count your output signals → 16 points covers most mid-size control panels
- Check your wiring logic → NPN (sinking) for OD212/OD213 | PNP (sourcing) for OD215
- Check your load current → Standard loads (≤0.1A): OD212 or OD213 | Higher current (≤1A): OD215
Where the CQM1-OD212 Is Used
The CQM1-OD212 controls discrete output signals across a wide range of industrial machinery:
- Packaging machines — carton folding, sealing, and labelling actuator control
- Assembly lines — part clamping, indexing, and reject gate activation
- Conveyor systems — belt drive enable/disable and diverter gate control
- Machine tools — coolant pump control, chuck actuation, tool change sequences
- Panel builders & OEM integrators — standard output module for CQM1-based control cabinets
- Maintenance replacement — direct swap for failed CQM1-OD212 units in existing installations
Shipping & Quality Guarantee
- 🔒 100% original Omron product — factory sealed
- 🔍 Pre-shipment inspection on every unit
- 📦 Original factory box with manufacturer label and serial identification
- 🌍 Worldwide express shipping available
- ⚡ In-stock orders dispatched within 1–2 business days
FAQ — Omron CQM1-OD212 Output Module
Q1: Is the CQM1-OD212 a genuine Omron product? Yes. Every unit we supply is a 100% original Omron CQM1-OD212, factory new and sealed in the original box. We do not supply aftermarket or remanufactured modules. Genuine Omron modules ensure full firmware compatibility and rated electrical performance in your CQM1 PLC system.
Q2: Which PLC systems is the CQM1-OD212 compatible with? The CQM1-OD212 is designed exclusively for the Omron CQM1 series PLC platform. It is not compatible with other Omron PLC families such as the CJ, CS, or CP series. Always confirm your existing PLC backplane and CPU model is CQM1 before ordering.
Q3: What is the difference between NPN and PNP output, and which does the CQM1-OD212 use? The CQM1-OD212 uses NPN (sinking) transistor outputs. In NPN wiring, the output pulls the load line to 0V (common) when active — the load connects between the output terminal and the positive DC supply. If your field devices require a PNP (sourcing) output, you need the CQM1-OD215 instead. Mixing NPN and PNP modules without rewiring will cause outputs not to function correctly.
Q4: Can the CQM1-OD212 control solenoid valves directly? It depends on the solenoid's current draw. The CQM1-OD212 is rated at 0.1A per output point. Most small pilot solenoid valves (24V DC) draw 0.06–0.1A and are compatible. Larger solenoids exceeding 0.1A will require an interposing relay or should be driven via the higher-current CQM1-OD215 (rated 1.0A per point).
Q5: Is the CQM1-OD212 a direct plug-in replacement for a failed module? Yes — it is a direct rack-mount replacement for any existing CQM1-OD212 installation. No PLC configuration or parameter changes are required; simply slot it into the same rack position. Ensure the PLC is powered down before swapping modules as a standard safety precaution.
Q6: The CQM1 is an older PLC series — is this module still available? Yes, we maintain stock of genuine CQM1-series modules to support the large installed base of CQM1 PLCs still running in factories worldwide. While Omron has transitioned to newer platforms, the CQM1 remains in active use and we can supply genuine replacement modules with fast worldwide shipping.
Q7: Do you offer bulk pricing for spare parts stocking? Yes. Many maintenance teams and panel builders stock multiples of the CQM1-OD212 as a critical spare. Contact us via WhatsApp or the Enquiry button with your required quantities for volume pricing and availability confirmation.
Need help confirming CQM1 module compatibility or identifying the right output module for your application? Our technical team is ready to assist.
