2094-BM05-S New Factory Sealed 2094BM05S Kinetix 6000 Servo Drive
PRODUCT DETAILS
2094-BM05-S — Kinetix 6000 Single-Axis Inverter Module, 5A, with Safety Option
The 2094-BM05-S is a single-axis inverter module for the Kinetix 6000 multi-axis servo platform, rated for 5A continuous output current. Unlike a converter-equipped module, this is a pure inverter — it draws DC bus power from a separate converter module on the same 2094 power rail rather than rectifying its own AC supply. The "-S" suffix indicates integrated hardwired safety functionality on this axis module, supporting safe-state outputs as part of the system's broader safety architecture.
Specifications
| Parameter | Value |
|---|---|
| Part Number | 2094-BM05-S |
| Series | Kinetix 6000 |
| Axis Output Current | 5 A continuous |
| Bus Connection | Shared DC bus via 2094 power rail (requires separate converter) |
| Communication | SERCOS or CIP Motion (platform/firmware dependent) |
| Safety Function | Hardwired safety inputs/outputs (-S variant) |
| Enclosure | IP20 |
| Operating Temperature | 0°C to 50°C |
Feedback and Safety Integration
- Feedback type and connector depend on the specific motor paired with this axis — verify compatibility between the motor's feedback device and this inverter's supported feedback interfaces before commissioning.
- The -S safety variant's hardwired safety connections must be wired into the machine's overall safety circuit and validated as part of the complete safety function — installing the module alone does not constitute a validated safety system.
- Confirm the axis's bus rail position follows the system's wiring sequence rules, since physical placement relative to the converter affects current distribution across the shared bus.
- Document the axis's safety wiring and test results separately from standard commissioning records, since safety functions require their own validation evidence distinct from general motion performance testing.
FAQ
Q: Can this inverter module run without any converter module on the bus?
No. This module has no AC rectifier of its own and depends entirely on a separate converter module supplying the shared DC bus for any operation.
Q: How many 2094-BM05-S modules can share one converter's bus?
This depends on the converter's total current rating and the combined demand of all axes sharing that bus — not a fixed module count. Verify the complete axis group against the converter's rated capacity using the platform's system sizing tools.
Q: Does the -S safety function require a dedicated safety controller?
Not necessarily — hardwired safety inputs on this module type can typically be driven by a standard safety relay. Whether a safety controller is needed depends on the broader machine safety architecture, not this module specifically.
Q: Is this module compatible with the Kinetix 5500 or 5700 platforms instead?
No. The 2094 series is specific to the Kinetix 6000 bus architecture and its power rail connector system — it is not interchangeable with the bus modules used in Kinetix 5500 or 5700 systems.
