MPL-B680D-SJ72AA New Original MPLB680DSJ72AA AC Rotary Servo Motor
PRODUCT DETAILS
MPL-B680D-SJ72AA Brushless Servo Motor for Precision Motion Control
The MPL-B680D-SJ72AA is a low-inertia brushless servo motor designed for precision positioning and high-performance motion control. It delivers fast response, smooth operation, and stable torque output, making it suitable for demanding automation systems that require accurate and repeatable movement.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Type | Brushless AC Servo Motor |
| Rated Voltage | 460 VAC |
| Rated Power | 9.3 kW |
| Rated Speed | 2000 rpm |
| Rated Torque | 62.8 Nm |
| Feedback | Single-turn High-Resolution Encoder |
| Motor Type | Low-Inertia Permanent Magnet Servo |
| Protection Rating | IP66 |
| Duty Cycle | S1 Continuous Duty |
| Mounting Type | IEC Metric Flange Mount |
| Brake | No Brake |
Typical Applications
- CNC machining centers
- Robotic systems
- Packaging equipment
- Semiconductor machinery
- Printing machines
- Precision assembly lines
FAQ
Q1: What type of encoder does it use?
A: It features a single-turn high-resolution encoder.
Q2: Is the motor suitable for continuous operation?
A: Yes, it is rated for S1 continuous duty.
Q3: What is the rated speed?
A: The rated speed is 2000 rpm.
Q4: Is a holding brake included?
A: No, this version is supplied without a brake.
Q5: What applications is it intended for?
A: It is designed for precision motion control in industrial automation.
