LQ043T3DW03 For Sharp 4.3-Inch New LCD Control Panel Display Module LQ043T3DW03
PRODUCT DETAILS
Product Title：Sharp LQ043T3DW03 4.3-Inch TFT LCD Display Module | New
Original Sharp LQ043T3DW03 4.3-inch TFT LCD display module with 480×272 resolution, LED backlight and RGB interface. Ideal for HMI and industrial control panels.
📝 Product Description
The Sharp LQ043T3DW03 is a 4.3-inch TFT LCD display module designed for industrial control and embedded system applications.
It features a 480×272 resolution, LED backlight, and RGB parallel interface, providing stable image output and long-term reliability.
This LCD module is suitable for HMI panels, PLC control systems, CNC machines, medical devices, and industrial automation equipment.
Condition: Brand New.
Application type: Industrial LCD display replacement and OEM integration.
📊 Key Attributes
| Google Attribute | Value |
|---|---|
| brand | Sharp |
| mpn | LQ043T3DW03 |
| condition | new |
| product_type | Industrial LCD Display Module |
| google_product_category | Electronics > Electronic Components > Display Modules |
| size | 4.3 inch |
| resolution | 480 x 272 |
| interface | RGB Parallel |
| backlight | LED |
| application | HMI / Industrial Control |
🔧 Key Features
-
4.3-inch TFT LCD display module
-
Resolution: 480 × 272 pixels
-
RGB parallel interface
-
LED backlight design
-
Stable signal transmission
-
Long-term industrial operation support
-
Standard size for control panel replacement
📊 Technical Specifications
| Item | Specification |
|---|---|
| Manufacturer | Sharp |
| Model | LQ043T3DW03 |
| Display Size | 4.3 inch |
| Display Type | TFT LCD |
| Resolution | 480 × 272 (WQVGA) |
| Aspect Ratio | 16:9 |
| Display Colors | 16.7M |
| Interface | RGB Parallel |
| Backlight | LED |
| Typical Brightness | 400 cd/m² |
| Contrast Ratio | 500:1 (typ.) |
| Response Time | 25 ms (typ.) |
| Operating Voltage | 3.3 V (logic) |
| Operating Temperature | −20°C to +70°C |
| Storage Temperature | −30°C to +80°C |
| Condition | New |
| Application | Industrial Control / HMI Display |
🏭 Typical Applications
-
Industrial HMI touch panels
-
PLC control cabinets
-
CNC machine operation displays
-
Automation control terminals
-
Industrial test instruments
-
Embedded control systems
🔄 Compatibility & Replacement
The Sharp LQ043T3DW03 can be used as a replacement LCD module for industrial equipment that requires:
-
4.3-inch TFT LCD size
-
480 × 272 resolution
-
RGB parallel interface
⚠️ Please verify interface pin definition and mechanical dimensions before installation.
📦 Package Contents
-
1 × LQ043T3DW03 4.3" LCD Display Module
-
Anti-static protective packaging
🔍 Keywords
Sharp LQ043T3DW03 LCD
4.3 inch LCD control panel display
Industrial TFT LCD module
480×272 LCD display module
HMI LCD replacement panel
✅ Why Choose This Module
-
Suitable for industrial automation systems
-
Stable performance for continuous operation
-
Standard 4.3-inch form factor
-
Easy integration into existing control panels
-
Ideal for maintenance replacement and OEM projects
