1769-OB16 Digital Output Module

The 1769-OB16 digital output module provides sixteen DC sourcing outputs for industrial control applications requiring reliable signal switching and stable field device operation. Its compact structure simplifies installation while maintaining dependable performance in distributed automation systems.

Technical Specifications

Parameter	Value
Product Type	Digital Output Module
Output Channels	16
Output Type	DC Sourcing
Output Voltage	24 VDC
Mounting	DIN Rail / Panel
Wiring	Removable Terminal Block
Operating Temperature	Industrial Environment
Status Indicators	Individual Channel LEDs

Installation Guide

Disconnect system power before wiring.
Mount the module securely on the DIN rail or compatible base.
Connect output wiring according to channel identification.
Verify power polarity before energizing the system.
Confirm channel status using the integrated LED indicators after startup.

Typical Applications

Packaging equipment
Conveyor control systems
Material handling lines
Automated assembly machines
Process control cabinets
Factory automation cells
Motor starter and relay control
Industrial machine sequencing

FAQ

Q1: What type of outputs does this module provide?
A: It provides sixteen DC sourcing digital outputs.

Q2: Can it control relays and solenoids?
A: Yes, it is commonly used for relays, contactors, indicator lamps, and solenoid valves.

Q3: Is DIN rail installation supported?
A: Yes, it supports standard DIN rail mounting.

Q4: How can output status be checked?
A: Individual LED indicators display channel operating status.

Q5: Where is this module commonly installed?
A: It is widely used in industrial control panels and automated production equipment.

1769-OB16 New Sealed 1769OB16 Compact I/O 32PT Sourcing Output Module
