Allen-Bradley 2198-S086-ERS4 Kinetix 5700 Servo Drive | Genuine Series A
Buy the Allen-Bradley 2198-S086-ERS4 — a genuine Series A Kinetix 5700 servo drive module engineered for high-precision multi-axis motion control. In stock and ready to ship worldwide for Rockwell Automation Logix-based systems.
Product Overview
The Allen-Bradley 2198-S086-ERS4 is a high-performance Kinetix 5700 series servo drive module from Rockwell Automation, designed for demanding multi-axis motion control applications in industrial automation. Rated at 86A nominal current and powered by EtherNet/IP communication, this drive delivers precise position, velocity, and torque control with seamless integration into Studio 5000 Logix Designer environments.
As a genuine Series A module, the 2198-S086-ERS4 is manufactured to strict Rockwell Automation factory standards, ensuring full compatibility, long-term operational stability, and reliable performance across a wide range of industrial applications — from robotic assembly to CNC machining and high-speed packaging lines.
Technical Specifications
| Specification | Details |
|---|---|
| Part Number | 2198-S086-ERS4 |
| Brand | Allen-Bradley (Rockwell Automation) |
| Product Series | Kinetix 5700 |
| Series Revision | A |
| Drive Type | Servo Drive Module |
| Rated Current | 86A (nominal, system-dependent) |
| Input Voltage | 380–480 VAC (3-Phase) |
| Communication Protocol | EtherNet/IP |
| Programming Software | Studio 5000 Logix Designer |
| Mounting Type | Panel Mount |
| Condition | Genuine New, Series A |
| Stock Status | In Stock – Ready to Ship |
Key Features & Advantages
- High-Precision Motion Control — Delivers accurate position, velocity, and torque regulation for high-speed, high-accuracy multi-axis applications with minimal positional error.
- EtherNet/IP Integrated Communication — Native EtherNet/IP connectivity enables real-time data exchange with Logix controllers, reducing communication latency and simplifying system configuration.
- Multi-Axis System Optimization — Purpose-built for coordinated motion in complex automation architectures, improving axis synchronization and overall machine throughput.
- Advanced Built-In Diagnostics — Continuous drive health monitoring reduces unplanned downtime and accelerates fault diagnosis during maintenance.
- Studio 5000 Native Integration — Full compatibility with Studio 5000 Logix Designer eliminates integration complexity and shortens commissioning time.
- Industrial-Grade Durability — Engineered to withstand continuous operation, vibration, and thermal stress in demanding factory environments.
- Genuine Series A Quality — Manufactured to strict Rockwell Automation OEM standards for consistent performance, traceability, and long-term reliability.
Typical Applications
Robotics & Automated Assembly Precise multi-axis motion control for robotic arms, pick-and-place systems, and coordinated assembly operations requiring high-speed cycle performance with minimal positioning error.
CNC & Machine Tools Accurate torque and velocity control for milling centers, lathes, and grinding machines. Smooth acceleration and deceleration profiles support complex multi-axis machining paths synchronized via Rockwell PLCs.
Packaging & Labeling Lines Consistent, repeatable motion for high-speed filling, labeling, and sorting systems. Built-in diagnostics reduce downtime and support coordinated motion between conveyors and actuators.
Material Handling & Conveyors Optimized speed and positioning for palletizers, sorters, and automated guided vehicles (AGVs) operating under heavy industrial load and vibration conditions.
High-Performance Manufacturing Ideal for production lines demanding tight positional accuracy and repeatability, integrated with EtherNet/IP networks for real-time monitoring and centralized Logix control.
Kinetix 5700 vs Competing Servo Drives
| Feature | 2198-S086-ERS4 (AB) | Siemens SINAMICS | Yaskawa Sigma-7 | Mitsubishi MELSERVO |
|---|---|---|---|---|
| Logix PLC Integration | Native / Seamless | Gateway Required | Gateway Required | Gateway Required |
| Communication | EtherNet/IP | PROFINET | EtherNet/IP | CC-Link / SSCNET |
| Multi-Axis Coordination | Kinetix Optimized | Good | Good | Good |
| Studio 5000 Support | Full Native | None | Limited | None |
| Global AB Support | Extensive | Extensive | Good | Good |
| Best For | AB Logix Ecosystems | Siemens PLC Systems | High-Speed Servo | Cost-Effective Precision |
For factories standardized on Allen-Bradley Logix platforms, the 2198-S086-ERS4 offers unmatched native integration, streamlined commissioning, and the full backing of Rockwell Automation's global support network.
Why Order From Us?
- ✅ Genuine Series A Unit — Original Allen-Bradley product, not refurbished or counterfeit
- ✅ In Stock — Ships within 1–3 business days
- ✅ Global Shipping — Worldwide delivery with full tracking
- ✅ Secure Packaging — Anti-static and shock-resistant for safe international transport
- ✅ 15+ Years Experience — Specialist supplier of Rockwell Automation and industrial automation components
- ✅ Technical Support — Pre-sale application and compatibility assistance via WhatsApp and email
FAQ — Allen-Bradley 2198-S086-ERS4 Kinetix 5700 Servo Drive
Q1: What is the Allen-Bradley 2198-S086-ERS4? The 2198-S086-ERS4 is a Kinetix 5700 series servo drive module from Allen-Bradley (Rockwell Automation). It is designed for multi-axis precision motion control in industrial automation systems, providing accurate position, velocity, and torque regulation via EtherNet/IP communication with Logix safety and standard controllers.
Q2: What does "ERS4" mean in the part number 2198-S086-ERS4? In the Kinetix 5700 naming convention, "ERS4" indicates the drive's communication and safety feature set. "ER" refers to EtherNet/IP single-axis drive capability, and "S4" denotes integrated safe torque-off (STO) and other safety functions certified to SIL 2 / PLd. Always verify the exact feature set against official Rockwell Automation documentation for your application.
Q3: Which controllers is the 2198-S086-ERS4 compatible with? The 2198-S086-ERS4 is designed for use with Rockwell Automation Logix controllers, including ControlLogix and CompactLogix platforms. It is programmed and commissioned using Studio 5000 Logix Designer. For multi-axis applications, it is paired with the Kinetix 5700 DC bus power supply within a shared DC bus architecture.
Q4: What is the rated current of the 2198-S086-ERS4? The nominal rated current is 86A, making it suitable for high-power servo motor applications. Actual current capacity depends on system configuration, bus voltage, ambient temperature, and motor selection. Always consult the official Rockwell Automation Kinetix 5700 selection guide to confirm sizing for your specific application.
Q5: What input voltage does the 2198-S086-ERS4 require? The drive accepts 380–480 VAC, 3-phase input power. It operates within the Kinetix 5700 shared DC bus architecture, where AC input is converted to DC at the bus power supply level and distributed to individual drive modules including the 2198-S086-ERS4.
Q6: Is this a genuine new module or a refurbished unit? This is a 100% genuine, brand new Allen-Bradley Series A unit. We do not supply refurbished, repaired, or aftermarket substitutes. All units are sourced as new OEM stock, quality-checked, and shipped in protective packaging.
Q7: Is the 2198-S086-ERS4 in stock and how quickly can you ship? Yes, this module is currently in stock. We typically dispatch within 1–3 business days. Estimated delivery is 5–12 business days depending on destination. Contact us for express shipping options if your project timeline is urgent.
Q8: What is the difference between 2198-S086-ERS4 and other Kinetix 5700 models? The Kinetix 5700 range includes multiple drive models differentiated by current rating, axis count (single vs. dual), and feature set. The 2198-S086-ERS4 is a single-axis, 86A drive with EtherNet/IP and integrated safety (STO). Other models in the range may offer lower current ratings, dual-axis configurations, or different safety feature levels. Contact our team with your motor and application requirements and we can help identify the correct model.
Q9: Can I use the 2198-S086-ERS4 with non-Rockwell PLCs? The 2198-S086-ERS4 is optimized for Rockwell Automation Logix controllers and Studio 5000 software. While EtherNet/IP is an open protocol, full drive functionality — including advanced motion instructions, safety integration, and diagnostics — requires a Logix-based controller. Using non-Rockwell PLCs will result in limited functionality and is not recommended or supported by Rockwell Automation.
Q10: Do you provide technical support or documentation? Yes. Our technical team can assist with compatibility verification, drive sizing guidance, and installation support. Contact us via WhatsApp (+86 186 2050 5228) or email at amy2013@topsdevice.com. For official documentation, Rockwell Automation's product page and literature library are also available.
Q11: What warranty and return policy applies? All products are covered under our standard warranty. Please visit our Refund Policy page for full details, or contact our support team for any post-purchase assistance.
