MPL-B680D-SJ72AA Brushless Servo Motor for Precision Motion Control

The MPL-B680D-SJ72AA is a low-inertia brushless servo motor designed for precision positioning and high-performance motion control. It delivers fast response, smooth operation, and stable torque output, making it suitable for demanding automation systems that require accurate and repeatable movement.

Product Specifications

Parameter	Specification
Product Type	Brushless AC Servo Motor
Rated Voltage	460 VAC
Rated Power	9.3 kW
Rated Speed	2000 rpm
Rated Torque	62.8 Nm
Feedback	Single-turn High-Resolution Encoder
Motor Type	Low-Inertia Permanent Magnet Servo
Protection Rating	IP66
Duty Cycle	S1 Continuous Duty
Mounting Type	IEC Metric Flange Mount
Brake	No Brake

Typical Applications

CNC machining centers
Robotic systems
Packaging equipment
Semiconductor machinery
Printing machines
Precision assembly lines

FAQ

Q1: What type of encoder does it use?
A: It features a single-turn high-resolution encoder.

Q2: Is the motor suitable for continuous operation?
A: Yes, it is rated for S1 continuous duty.

Q3: What is the rated speed?
A: The rated speed is 2000 rpm.

Q4: Is a holding brake included?
A: No, this version is supplied without a brake.

Q5: What applications is it intended for?
A: It is designed for precision motion control in industrial automation.

MPL-B680D-SJ72AA New Original MPLB680DSJ72AA AC Rotary Servo Motor
