Autonics E50S8-500-3-T-1 incremental rotary encoder

The Autonics E50S8-500-3-T-1 is an incremental rotary encoder belonging to the E50S series. This series consists of shaft-type incremental rotary encoders with an outer diameter of 50mm, and now includes a new Line Driver output type with a 12-24VDC power supply, designed to provide a cost-effective solution for industrial applications. 1. Main Features and Specifications: This encoder is suitable for measuring parameters such as angle, position, rotational speed, velocity, acceleration, and length. It supports a power supply voltage of 5VDC or 12-24VDC (with a ±5% tolerance), a resolution of up to 500 P/R (pulses per revolution), a push-pull output type, and axial wiring connection. Its dimensions are an outer diameter of 50mm and a shaft diameter of 8mm, and its protection rating and operating temperature range are suitable for standard industrial environments. 2. Applications and Precautions: This encoder is widely used in position control of industrial machinery, such as manual machinery, forming machinery, and packaging machinery. By converting the rotation of the rotating shaft into a pulse signal, it helps the control unit to accurately count and calculate, thereby improving control accuracy.
