Pilz PNOZ ma1p 773812 Analog Input Expansion Module for PNOZmulti Safety Systems

The Pilz PNOZ ma1p 773812 analog input expansion module extends PNOZmulti configurable safety controllers with analog signal processing capabilities. It supports voltage and current input signals, providing reliable acquisition of analog process values for safety-related monitoring and industrial automation applications.

Product Specifications

Product Specifications	Details
Brand	Pilz
Model	PNOZ ma1p
Order Number	773812
Product Type	Analog Input Expansion Module
Supply Voltage	24 VDC
Analog Inputs	2 Channels
Input Range	±10 V, 0–25 mA
Mounting	DIN Rail
Compatible System	PNOZmulti Safety Controller

Product Features

Supports two independent analog input channels
Accepts voltage and current process signals
Integrates directly with PNOZmulti safety systems
Compact DIN rail design for control cabinets
Reliable analog monitoring for safety applications

Typical Applications

Machine safety systems
Process monitoring
Industrial automation equipment
Safety control cabinets
Manufacturing production lines

Installation Guide

Mount the module on a standard DIN rail.
Connect the module to the PNOZmulti base unit.
Wire analog input signals according to the terminal diagram.
Configure input parameters using the controller software.
Verify analog signal values before commissioning.

FAQ

Q1: What is the primary function of PNOZ ma1p?
A: It expands a PNOZmulti controller with analog input capability.

Q2: How many analog inputs are available?
A: Two independent analog input channels.

Q3: Which signal types are supported?
A: Voltage (±10 V) and current (0–25 mA) signals.

Q4: Where is this module typically installed?
A: Inside industrial control cabinets on a DIN rail.

Q5: Which systems is it compatible with?
A: Pilz PNOZmulti configurable safety controller systems.

773812 New Original 773812 Pilz Pnoz Ma1P Analog Input Module 2 Input 24VDC
